Vertebrate Diversity
Class Actinopterygii — Ray-finned Fishes

(Click on any image for larger version)

Osteichthyes Characteristics

  • Endochondral (from cartilage) bone
  • Operculum covers gill openings
  • Complex skull structure
  • Fin rays (lepidotrichia)
  • Air sac functions as lung or swim bladder
  • Ganoid, cycloid, or ctenoid scales
  • Most have homocercal tail

Actinopterygii Characteristics

  • Very diverse: 44 Orders, 453 Families, over 27,000 species
  • Fins supported entirely by multiple fin rays
  • Single dorsal fin (though it may be subdivided)
  • Ganoid (primitive) or cycloid (derived) scales
  • 4 primitive Orders (51 species total); rest belong to clade "Teleostei"
See also
Bony Fish Anatomy page

Primitive (Non-teleost) Ray-finned Fishes


Order Polypteriformes — Bichirs

  • Covered in thick, interlocking ganoid scales
  • Elongated body
  • Dorsal fin with multiple finlets, each supported by spine
  • Paired lungs
  • 16 species; Africa
Bichir
Senegal Bichir, Polypterus senegalus

Order Acipenseriformes — Sturgeons & Paddle Fish

  • Cartilagenous skeleton (secondarily derived)
  • Heterocercal tail
  • 2 families that appear very different:
    Sturgeons: note 5 rows of bony scutes; protrusible downward-facing jaws (for bottom feeding)
    Paddle fish: note greatly elongated rostrum (used to detect electrical signals of prey)
  • 27 species; Temperate rivers; some sturgeons are anadramous
River Sturgeon
River Sturgeon, Acipenser sp.
Paddlefish
American Paddlefish, Polyodon spathula

Order Lepisosteiformes — Gars

  • Elongated, tubular body; 1-4 m long
  • Greatly elongated, well-toothed jaws
  • Large, non-overlapping ganoid scales
  • Ambush predators
  • 7 species; North and Central America
Longnosed Gar
Spotted Gar, Lepisosteus oculatus
Longnosed Gar
Long-nosed Gar, Lepisosteus osseus

Order Amiiformes — Bowfin

  • Mobile maxilla (shared with Teleosts)
  • Cycloid scales (shared with Teleosts)
  • Single large lung
  • Stout body
  • Skull and jaws largely solid
  • 1 species; southeastern North America
Bowfin Specimen
Bowfin, Amia calva
(see Bony Fish Anatomy page for a Bowfin skull)
Bowfin Specimen
Bowfin, Amia calva, closeup of head

Subclass Teleostei — Teleost Fishes

Characteristics

  • Includes vast majority of bony fishes
  • Mobile maxilla and premaxilla
  • Homocercal tail
  • Wide variety of body forms
  • ≈27,000 species divided into 40 Orders

See also
Bony Fish Anatomy page


Order Osteoglossiformes

  • Arawans, Elephantfishes and relatives
  • Elongated body
  • Teeth on "tongue bones"
  • Fewer than 16 rays in dorsal fin
  • The most primitive of the teleost fishes
  • 218 species; fresh water, mostly in Africa
Arawana
Silver Arowana, Osteoglossum bicirrhosum (Family Osteoglossidae)
Elephantfish
Peter's Elephantfish, Gnathonemus petersii (Family Mormyridae)
Knifefish
African Knifefish, Xenomystus nigri (Family Notopteridae)
Lycoptera fossil
Lycoptera sp. fossil (Family Lycopteridae); Early Cretaceous, China
Osteoglossiformes have an extensive fossil record and were common during the Mesozoic Era
Xiphactinus Fossil
Xiphactinus audax fossil; late Cretaceous of North America;
An extinct 5m long fish usually placed in closely related order Ichthyodectiformes
Xiphactinus
Xiphactinus audax model

Order Anguilliformes

  • True Eels
  • Greatly elongated snake-like body
  • Lack pelvic fins and often lack pectoral fins
  • Dorsal & anal fins contiguous with caudal fin: tail pointed
  • Scales deeply imbedded or absent
  • ≈800 mostly marine species
Green Moray
Green Moray Eel, Gymnothorax funebris (Family Muraenidae)
Garden Eels
Splendid Garden Eels, Gorgasia preclara (Family Congridae)
Spotted Garden Eel
Spotted Garden Eel, Heteroconger hassi (Family Congridae)

Order Clupeiformes

  • Shad, herring, sardines
  • Generalized bodies
  • Usually have silvery bodies
  • Lack lateral lines
  • 364 species; pelagic; feed on plankton
  • Many are commercially valuable
Sardines
Pacific Sardines, Sardinops sagax (Family Clupeidae)
Knightia fossil
Knightia oecana fossil (Family Clupeidae); an extinct freshwater herring from the Eocene of WY (48 mya)

Order Cypriniformes

  • Minnows, carp, loaches
  • Lack adipose fin
  • No scales on head
  • Diverse body forms
  • ≈3300 species; fresh waters, mostly in Northern Hemisphere
  • Taxonomic note: This and the following 2 orders (Characiformes and Siluriformes) constitute most of a monophyletic clade (the Ostariophysi) of mostly fresh water fish
Carp
Common Carp, Cyprinus carpio (Family Cyprinidae), breeding aggregation; PA
Borneo Sucker
Robust Redhorse, Moxostoma robustum (Family Catostomidae)
Borneo Sucker
Borneo Sucker, Gastromyzon borneensis (Family Balitoridae)
Rosyside Dace
Rosyside Dace, Clinostomus funduloides (Family Cyprinidae)
White Cloud Mountain Minnow
White Cloud Mountain Minnow, Tanichthys albonubes (Family Cyprinidae)

Order Characiformes

  • Characins, Tetras, Piranha
  • Laterally compressed, fusiform bodies
  • Adipose fin present
  • Diurnal: generally silvery or colorful and with large eyes
  • ≈1700 species; fresh waters of Latin America, Africa
Characin
African Red-eyed Tetra, Arnoldichthys spilopterus (Family Alestidae)
Hatchetfish
Common Hatchetfish, Gasteropelecus sternicla (Family Gasteropelecidae)
Pristella Tetra
Pristella Tetra, Pristella maxillaris (Family Characidae)
Neon Tetra
Neon Tetra, Paracheirodon innesi (Family Characidae)
Piranha
Red-bellied Piranha, Pygocentrus nattereri (Family Serrasalmidae)
Payara
Payara, Hydrolycus scomberoides (Family Cynodontidae)

Order Siluriformes

  • Catfishes
  • Skin scaleless or with bony plates
  • Flattened head, broad mouth
  • Mouth surrounded by 1-4 pairs of barbels ("whiskers")
  • Eyes small: nocturnal or in murky water
  • ≈2900 species; worldwide mostly in fresh water
Channel Catfish
Channel Catfish, Ictalurus punctatus (Family Ictaluridae)
Sailfin Pleco
Amazon Sailfin Pleco, Pterygoplichthys pardalis (Family Loricariidae)
Three-lined Cory
Three-lined Cory, Corydoras trilineatus (Family Callichthyidae)
Shovel-nosed Catfish
Shovel-nosed Catfish, Sorubim lima (Family Pimelodidae)
Glass Catfish
Glass Catfish, Kryptopterus bicirrhis (Family Siluridae)
Electric Catfish
Electric Catfish, Malapterurus electricus (Family Malapteruridae)

(Order Salmoniformes)

  • Salmon & trout
  • Mostly fairly large size
  • Scales usually very fine
  • 66 species; in northern hemisphere rivers (some anadramous)
  • Some species commercially valuable
Rainbow Trout
Rainbow Trout, Oncorhynchus mykiss (Family Salmonidae)
Brook Trout
Brook Trout, Salvelinus fontinalis (Family Salmonidae)
Brown Trout
Brown Trout, Salmo trutta (Family Salmonidae)

(Order Lophiiformes)

  • Frogfish, batfish, anglerfish
  • In most, dorsal spine modified into lure
  • In some, pectoral fins modified for walking
  • Odd appearance, often cryptically shaped & colored
  • 313 benthic marine species, mostly in deep water
Frogfish
Frogfish, Antennarius sp. (Family Antennariidae)
Footballfish
Pacific Footballfish, Himantolophus sagamius, preserved specimen (Family Himantolophidae)
Cabrillo Marine Aquarium

(Order Beloniformes)

  • Dorsal and anal fin similar in size and close to tail
  • Several distinctive families, including:
    Needlefishes have very long jaws
    Flying fishes have greatly enlarged pectoral fins for gliding above the water
  • 227 species, pelagic in both marine and fresh water
Garfish specimen
Needle-nosed Garfish, Xenentodon cancila (Family Belonidae), preserved specimen
Flying Fish specimen
Flying Fish, Cypselurus sp. (Family Exocoetidae), preserved specimen

Order Cyprinodontiformes

  • Top-minnows, live-bearers, killifishes
  • Small size (< 15 cm)
  • Pelvic fins usually absent
  • Rounded caudal fin
  • Some have internal fertilization and are viviparous
  • Males of some have a gonopodium (modified anal fin for mating)
  • ≈1000 mostly fresh-water species
  • Many occur in harsh environments (brackish marshes, hot springs, isolated pools) unsuitable for other fish
Molly
Black Molly, Poecilia sphenops (Family Poeciliidae)
Mosquitofish
Western Mosquitofish, Gambusia affinis (Family Poeciliidae)
Killifish
Rivuline Killifish, Rivulus sp.? (Family Rivulidae)

Order Syngnathiformes

  • Pipefishes, seahorses, seamoths
  • Atypically shaped, usually elongated
  • Body armored with various plates
  • Small mouth, usually at end of long snout
  • 264 species in shallow marine waters
  • Taxonomic note: sometimes placed with sticklebacks in the order Gasterosteiformes
Seahorse
Pacific Seahorse, Hippocampus ingens (Family Syngnathidae)
Sea Dragon
Leafy Sea Dragon, Phycodurus eques (Family Syngnathidae)
Razorfish
Razorfish, Aeoliscus strigatus (Family Centriscidae)
Yellow-banded Pipefish
Yellow-banded Pipefish, Syngnathoides biaculeatus (Family Syngnathidae)
Snipefish
Longspine Snipefish, Macroramphosus scolopax (Family Centriscidae)
Seamoth
Long-tailed Seamoth, Pegasus volitans (Family Pegasidae)

Order Scorpaeniformes

  • Rockfish, lionfish, Sculpins, etc.
  • Large-headed
  • Large, rounded pectoral and dorsal fins
  • Have either numerous spines or armor plates
  • ≈1500 bottom-dwelling, mostly marine species
Lionfish
Lionfish, Pterois sp. (Family Scorpaenidae)
Stone Scorpionfish
Stone Scorpionfish, Scorpaena mystes (Family Scorpaenidae)
China Rockfish
China Rockfish, Sebastes nebulosus (Family Sebastidae)
Grunt Sculpin
Grunt Sculpin, Rhamphocottus richardsoni (Family Cottidae)
Pacific Spiny Lumpsucker
Pacific Spiny Lumpsucker, Eumicrotremus orbis (Family Cyclopteridae)
Tidepool Sculpin
Tidepool Sculpin, Oligocottus maculosus (Family Cottidae); CA

Order Perciformes

  • Diverse with varied shapes
  • Typically are moderately elongate and deep-bodied
  • Typically have double or 2-part dorsal fin
  • Lack adipose fin
  • Pelvic fins positioned close to pectoral fins (or absent)
  • Typically have relatively large eyes and mouth
  • Ctenoid scales
  • Most species-rich order of vertebrates: ≈10,000 species
  • Includes majority of fishes associated with coral reefs
  • Taxonomic Note: relationships uncertain; likely to be paraphyletic or polyphyletic
Rainbow Runners
Rainbow Runners, Elagatis bipinnulata (Family Carangidae)
Lookdown
Lookdown, Selene vomer (Family Carangidae)
Dwarf Gourami
Dwarf Gourami, Colisa lalia (Family Belontiidae)
Zebra Goby
Zebra Goby, Lythrypnus zebra (Family Gobiidae)
Kelpfish
Kelpfish, Gibbonsia sp. (Family Clinidae)
Barracuda
Great Barracuda, Sphyraena barracuda (Family Sphyraenidae)
Clarion Angelfish
Clarion Angelfish, Holacanthus clarionensis (Family Pomacanthidae)
Angelfish
Angelfish, Pterophyllum scalare (Family Cichlidae)
Cardinalfish
Banggai Cardinalfish, Pterapogon kauderni (Family Apogonidae)

Order Pleuronectiformes

  • Flatfishes, flounders
  • Body greatly flattened laterally
  • Lay on one side on ocean bottom
  • One eye moves to opposite side of face
  • Dorsal, anal, & caudal fins almost completely surround body
  • ≈700 species of predominantly benthic marine fishes
Starry Flounder
Starry Flounder, Platichthys stellatus (Family Pleuronectidae)
Sanddab
Sanddab, Citharichthys sp. (Family Paralichthyidae)
Fantailed Sole
Fan-tailed Sole, Xystreurys liolepis (Family Bothidae)

Order Tetraodontiformes

  • Puffers, triggerfish, etc.
  • Non-streamlined, bulky shape
  • Slow (ostraciform) swimmers
  • Hard, powerful jaw with beak-like teeth
  • Most specialize on hard or spiny prey
  • 357 species; mostly tropical marine
Pacific Boxfish
Pacific Boxfish, Ostracion meleagris (Family Ostraciidae)
Clown Triggerfish
Clown Triggerfish, Balistoides conspicillum (Family Balistidae)
Puffer
Figure-8 Puffer, Tetraodon biocellatus (Family Tetraodontidae)
This page last updated 31 December 2011 by Udo M. Savalli ()
Images and text © Udo M. Savalli. All rights reserved.
